POWERFLEX® PLUS YMvKf, flexible cable connections

Q: What does CPR Cca-s2,d2,a3 mean? What is CPR in a cable?

Here you can read more about the European Construction Products Regulation (CPR) and its fire performance classification system for electrical cables . The CPR classification of TOP CABLE POWERFLEX® PLUS YMvKf cable is Cca-s2,d2,a3 . In several European countries, the installation of CPR Cca cables is mandatory in public places such as: hospitals, schools, museums, airports, bus stations and shops in general.

Q: What international certifications does the cable meet?

The cablemeets the following certificates: AENOR, BUREAU VERITAS, KEMA-KEUR, CE and RoHS .

Q: Where can I find POWERFLEX® PLUS YMvKf cable technical specification in PDF format?

Here is the PDF of the summary technical specification of the cable . If you need to consult additional technical aspects of this cable, such as its maximum admissible current or voltage drop, please contact us .

Top Cable POWERFLEX® PLUS YMvKf, an extra-flexible cable, is the universal cable for power transmission with improved fire proof properties. This cable is suitable for curved routes and difficult layouts, making the installation substantially easier. It is also perfect for installation in ducts, conduits or channels without requiring additional protection.

Datasheet

Contact

DESIGN:

1 – Electrolytic annealed copper conductor (class 5).

2 – Cross-linked polyethylene insulation, type XLPE.

3 – Flexible PVC outer sheath type ST2.

INDEX

AN EASY-TO-HANDLE-CABLE

Powerflex^® PLUS YMvKf is a flexible and easy-to-handle cable, which guarantees maximum performance and safety. Its flexibility allows for greater agility in handling the cable in installations with more complex layouts. This greatly facilitates the work of the installers, who see a reduction in the time spent covering the entire layout and, consequently, significantly reduces the final cost of the project’s labour.

TECHNICAL CHARACTERISTICS OF POWERFLEX® PLUS YMvKf

Le câble se distingue par son extrême flexibilité, mais il présente également d’autres caractéristiques techniques pour l’installation.

AD7 (immersion)

UV resistant

High flexible cable

Maximum conductor temperature: 90ºC

WEATHERPROOF AND UV-RESISTANT OUTER SHEATH

The Powerflex^® PLUS YMvKf is a cable that is highly resistant to the different environmental conditions and aggressions that it may suffer in its installation environment. Its outer sheath is resistant to moisture and chemicals. It withstands wet conditions and even total immersion in water (AD7). It also has enhanced ultraviolet (UV) properties, making it resistant to ultraviolet radiation according to the UNE 211605 climatic test. This capability makes it a fully guaranteed cable that can be installed in a wide variety of environments, both indoors and outdoors, dry or wet, without affecting its correct performance.

INSTALLATIONS WHERE IT IS ADVISABLE TO USE THIS CABLE

POWERFLEX® PLUS YMvKf cable, manufactured by Top Cable, is design makes it one of the most suitable cables for all types of low-voltage industrial connections in public areas such as building installations, urban grids, and all types of industrial low voltage connections.

Industrial use.
Public places
Outdoor.

WHERE CAN I BUY POWERFLEX® PLUS YMvKf CABLES?

To buy this cable, please see our sales conditions for Electrical Wholesalers and Distributors here. We can also put you in touch with your nearest Top Cable distributor.

Some of the most common electrical cable cross-sections in immediate stock are as follows:

Cable	Conductor cross-section (mm²)	Conductor outer sheath colour
POWERFLEX® PLUS YMvKf	1 x 10	Grey
POWERFLEX® PLUS YMvKf	1 x 16	Grey
POWERFLEX® PLUS YMvKf	1 x 25	Grey
POWERFLEX® PLUS YMvKf	2 x 25	Grey
POWERFLEX® PLUS YMvKf	3G 10	Grey
POWERFLEX® PLUS YMvKf	3 x 16	Grey

Most common TOP CABLE POWERFLEX® PLUS YMvKf power cable cross-sections in immediate stock

If you need to consult additional technical aspects of POWERFLEX® PLUS YMvKf cable, such as its maximum admissible current or voltage drop, please contact us.

FREQUENTLY ASKED QUESTIONS (FAQ) ABOUT THE POWERFLEX® PLUS YMvKf CABLE

What is the difference between a portable cable and a power cable?

A portable cable is designed for temporary power supply, whereas power cables are usually installed in permanent applications.

What is the fire performance of these cables?

This cable is fire retardant and is recommended for use in public places and hazardous industries.

Flame non-propagation based on EN 60332-1 and IEC 60332-1.
Fire non-propagation based on EN 60332-3 / IEC 60332-3 / NBN C 30-004-F2 / EN 50399.
Reduced halogen emission. Chlorine <15%.
Reaction to fire CPR: Cca-s2,d2,a3 according to EN 50575.

What does CPR Cca-s2,d2,a3 mean? What is CPR in a cable?

Here you can read more about the European Construction Products Regulation (CPR) and its fire performance classification system for electrical cables.
The CPR classification of TOP CABLE POWERFLEX® PLUS YMvKf cable is Cca-s2,d2,a3. In several European countries, the installation of CPR Cca cables is mandatory in public places such as: hospitals, schools, museums, airports, bus stations and shops in general.

What international certifications does the cable meet?

The cablemeets the following certificates: AENOR, BUREAU VERITAS, KEMA-KEUR, CE and RoHS.

Where can I find POWERFLEX® PLUS YMvKf cable technical specification in PDF format?

Here is the PDF of the summary technical specification of the cable. If you need to consult additional technical aspects of this cable, such as its maximum admissible current or voltage drop, please contact us.
