POWERFLEX® RV-K, the cable that solves any curve in the routing with its high flexibility
The POWERFLEX® RV-K cable is a flexible power cable designed to circumvent the difficulties of complex installation layouts. Moreover, thanks to the design of its materials, it can be installed in all types of environmental conditions (wet and dry areas, outdoors, buried and even submerged in water).
DESIGN:
1 – Electrolytic annealed copper conductor, class 5 (flexible) .
2 – Cross-linked polyethylene insulation type DIX-3 and flexible (XLPE).
3 – Flexible PVC outer sheat type DMV-18 and ST2.
DESIGNED TO MAKE THE INSTALLER’S LIFE EASIER
POWERFLEX® RV-K is an ultra-flexible power cable designed to meet the most demanding industrial requirements. Its great flexibility is great news for installers, who will find it simplifies their work when installing the cable in complex layouts.
This ease of installation not only influences the work of the technician carrying out the work, the flexibility of the cable also minimises the costs of the project, as the flexibility of the cable will save a lot of time spent on the project and consequently reduce the cost of labour. This advantage is particularly noticeable in large cable cross-sections, e.g. 4×150 mm2 cables.
Also noteworthy is its ability to not crack under vibration due to its flexible copper conductors.
TECHNICAL CHARACTERISTICS
Above all, the cable stands out for its extreme flexibility, but beyond that, it has other very interesting technical features for installation, such as a higher thermoelectric capacity of its conductor compared to other PVC-insulated conductors.
AD8 (submersion)
High flexible cable
Maximum conductor temperature: 90ºC
Minimum service temperature: -40ºC
INSTALLATIONS WHERE IT IS ADVISABLE TO USE THIS CABLE
POWERFLEX® RV-K cable, manufactured by Top Cable, is especially recommended in demanding circuits thanks to its flexibility. It is also very suitable for outdoor, emergency installations in public places such as: hospitals, airports, tunnels, subways, etc. as well as in offices, production plants, laboratories, etc.
- Industrial use.
- Outdoor lighting.
It can be installed in the open air, in conduit and/or buried in indoor and outdoor installations.
WHERE CAN I BUY THE POWERFLEX® RV-K CABLE?
To buy this cable on reels of various sizes, please see our sales conditions for Electrical Wholesalers and Distributors here. We can also put you in touch with your nearest Top Cable distributor.
Some of the most common electrical cable sections in immediate stock are as follows:
| Cable | Conductor cross-section (mm2) | Colour of conductor |
| POWERFLEX® RV-K | 1 x 2,5 | Black |
| POWERFLEX® RV-K | 1 x 4 | Black |
| POWERFLEX® RV-K | 1 x 6 | Black |
| POWERFLEX® RV-K | 3G 1,5 | Black |
| POWERFLEX® RV-K | 3G 2,5 | Black |
| POWERFLEX® RV-K | 3G 4 | Black |
| POWERFLEX® RV-K | 4G 1,5 | Black |
| POWERFLEX® RV-K | 4G 2,5 | Black |
If you need to consult additional technical aspects of this cable, such as its maximum admissible current or voltage drop, please contact us.
FREQUENTLY ASKED QUESTIONS (FAQ) ABOUT THE POWERFLEX® RV-K CABLE
What is a power cable?
Power cables are designed for permanent use and consist of one or more electrical conductors with a sheath. It is available in various constructions, materials and ratings for different applications.
What is the difference between a portable cable and a power cable?
A portable cable is designed for temporary power supply, whereas power cables are usually installed in permanent applications.
Which power cables are most commonly used?
Class 5 (flexible) copper power cable, such as POWERFLEX® RV-K. This type of cable is suitable for the transmission of electrical power in all types of industrial low-voltage connections, in urban networks, building installations, etc. The power cables consist of a copper conductor, a protective insulation and an outer sheath.
What other features does the POWERFLEX® RV-K cable have?
In addition to all the characteristics explained so far, we can also highlight the following:
Maximum short-circuit temperature: 250°C (maximum 5 s).
Minimum installation and handling temperature: 0°C (on the cable surface).
Reduced halogen emission. Chlorine < 15%.
Impact resistance: AG2 Medium severity.
CPR Eca certification.
What certifications does the cable meet?
Where can I find the POWERFLEX® cable technical specification in PDF format?
Here is the PDF of the summary technical specification of the POWERFLEX® RV-K cable. If you need to consult additional technical aspects of this cable, such as its maximum admissible current or voltage drop, please contact us.
